Tower pro Outrunner Brushless Motor Type 2409-18 W/Back Cove/ Pr

Tower pro Outrunner Brushless Motor Type 2409-18 W/Back Cove/ Prop adaptor

Towerpro outrunner bushless motor type 2409-18 W/ prop adaptor.

2409-Series Motors for indoor sport-flyer, trainer-flyer,F3A and park-flyer modelsï¼›

The high performance outrunner design features, All motors include hardware pack which features prop adapters, mounting hardware.

We recommend 30A ESC for use with the 2409 Series Motors.

(Note: the color of prop adaptor may different form the picturer.)

Weight:65g

Size:Ф31*62.0

Output Axis:M3

Current:8.2A/12.7A

BATTERY: 3-4 cells Lipo

KV:1000

PROPOLLER: 8×4 APC/8×5

Recommended Applications:

a. 2 cell Lipo:5300RPM 7.2V 9.7A Thrust 510 gram ( Air pressure 76mmHg/25 centigrade)

Suit for small 3D airplanes with fly weight around 350 gram. using 1000mAh 10C liPoly and 12A Electric speed controller.

b. 3 cell lipo: 10×5 APC-E prop; 7200RPM 10V 12.7A Thrust 718 gram ( Air pressure 76mmHg/25 centigrade)

Suit for sports airplanes and scale airplanes with fly weight between 500-800 gram, using 1300mAh 10C Lipo and 15A-18A electric speed controller ( ESC ).

c. 4 cell Lipo: 8×4 APC-E prop; 11600RPM; 14V 14.8A; thrust 883 gram ( Air pressure 76mmHg/25 centigrade)

Suit for small F3A ( 10-15 class) airplanes. Recommend to use with 1300mAh 12C or 1600mAh 10C above li-poly battery and 18A above ESC.

Voltage

Prop

Typical Current(A)

Peak Current(A)

Typical Thrust(g)

Max Thrust(g)

RPM/V

Internal Resistance(Ω)

11.1V

GWS Direct Drive 10×4.7

13

16

700

860

585

0.172

11.1V

GWS Direct Drive 9×4.7

9

12

660

760

693
